Super Racing suspension for EVO VIII

PART NUMBER: VSR52-K1LS4

Genuine Tein
Performance is improved to maintain the handling at high-speed and to avoid putting the vehicle off-balance; e.g. prevent nose dives while breaking. Helper springs are used on both front and rear to secure the sufficient rebound strokes and to allow for the better ground contact and traction performance. Use of caster and camber adjustable pillow ball upper mounts on front provides wider alignment adjustment range.

EDFC Compatibility: ○

Note
Camber adjustment washers with different offsets are available (sold separately).
From the positive angle set with the included washers, replace the washers with optional washers ‘sps12-r16100-25’ to set the angle further positive, and with ‘sps12-r16100-05’ to set to negative direction (both sold separately).
From the negative angle set with the included washers, replace the washers with optional washers ‘sps12-r16100-05’ to set the angle further negative, and with ‘sps12-r16100-25& to set to positive direction (both sold separately).
4 eccentric washers per vehicle are required.
Front springs: selected from 14, 16, 18k.
Rear springs: selected from 14,16k.
Springs must be selected when ordering. Price includes springs.
